신뢰성 높은 검사 데이터 실현
혈액을 정량하는 샘플링 밸브 방식, 정도 관리 프로그램 및 자기진단 프로그램 등 다양한 노하우를 컴팩트한 기기에 응축했습니다.
간단한 조작으로 신뢰도 높은 검사
샘플을 흡인 피펫에 셋팅후 스타트 스위치를 누르는 것만으로 간단히 조작할 수 있습니다. 피펫을 닦을 필요도 없습니다. 또한 시안화합물(Cyanide)을 사용하지 않는 헤모글로빈 측정법을 사용하여 안전한 검사 환경을 실현하고 있습니다. 시약 관리도 바코드 리더기로 간단하고 정확하게 할 수 있습니다.
보기 편한 디스플레이
측정 데이터 표시에 크고 보기 쉬운 터치 판넬 디스플레이를 사용합니다. 또한 문제해결을 대화방식으로 알기 쉽게 표시하는 도움말 기능을 갖추고 있으며, 한국어 설정도 가능하고 사용자의 편의를 고려하여 설계하였습니다.
"이 제품은 "의료기기"이며, "사용상의 주의사항"과 "사용방법"을 잘 읽고 사용하십시오"
이 제품은 "의료기기"이며, "사용상의 주의사항"과 "사용방법"을 잘 읽고 사용하십시오
광고심의필 : 심의번호 2014-I10-32-2183
Twenty parameters at the push of a button – in both modes
The XP-300 offers a total of 20 parameters. Regardless of whether you are analysing a blood sample in whole blood or pre-diluted mode, the analysis result provides values for all 20 parameters. The XP-300 delivers the classic CBC plus advanced 3-part differentiation of white blood cells, including a neutrophil count , and so offers information with superior clinical utility.
It's all about you, the user
Thanks to a colour LCD touch screen and unique reagent barcode system, the XP-300 is easy to use. Using a hand-held barcode reader, you can register reagents safely, simply and quickly and so improve your lab’s productivity. And because assay values are entered via barcodes, quality control is simplified significantly too.
Software, data handling and networking made easy
The unique barcoding of the XP-300‘s reagent and the integrated reagent management system will help you meet the growing regulatory demands with respect to documentation, accreditation and traceability. You can also add an Operator ID that is then included on printouts and transmitted to the Host.
This new instrument is easier to service thanks to its error log capacity and a new type of memory card. It is also easier to set up and update the analyser, and back up and restore user data and settings.
The XP-300 offers additional software languages and with room for some 40,000 samples provides a significantly increased data storage capacity. Thanks to improved and expanded interfaces, you can connect the XP-300 to the LIS and SNCS via its additional LAN port, to an external printer, and to Online quality control.
At Sysmex, we are known around the world for the excellence of our products. We are on a journey on which we always aim to excel. One key area is making sure our products truly meet the needs of our customers on all levels. And this includes their design.
Design is far more than just the way a product looks. It influences the entire user experience. Our answer is our Silent Design concept.
Silent Design is not about sound. It is about distilling products down to the essence. Providing our users with what they really need. Making the experience precise and elegant. And ensuring our products are unobtrusive yet distinctly powerful.
Within our Silent Design concept, we are focusing on five main principles to continuously improve the user experience.
Our Silent Design products take into account five key principles to create a positive experience. Between the product and the person. By making great use of the available space. Thanks to easy interaction with the device. Consistency in looks and operation. And an assurance of long product lifecycles.
The result? Products that are unmatched in terms of technology, offer a superb user experience, and reflect our global leadership position.
Parameters 20 in whole blood mode and pre-diluted mode
WBC, RBC, HGB, HCT , MCV, MCH, MCHC, PLT, LYM% (W-SCR),
MXD% (W-MCR), NEUT% (W-LCR), LYM# (W-SCC ), MXD# (W-MCC ),
NEUT# (W-LCC ), RDW-SD, RDW-CV, PDW, MPV, P-LCR, PCT Technologies DC detection method (WBC, RBC/PLT)
non-cyanide haemoglobin detection method (HGB) Throughput approx. 60 samples per hour Sample volume approx. 50 μL (whole blood mode)
approx. 20 μL (pre-diluted mode) Data storage up to 40,000 samples including histograms Quality control 6 files for 60 data sets each (internal QC)
IQAS Online (external daily QC) via SNCS and use of Eightcheck-3WP
(control blood) Scope of supply main unit plus hand-held barcode reader for reagent management
and traceability Interfaces colour LCD touch screen (user interface)
built-in thermal printer (standard)
external printer (optional)
hand-held barcode reader (standard)
SNCS capability (dedicated LAN port)
LIS (additional LAN port) Dimensions/weights main unit
w x h x d [mm] / [kg]
420 x 480 x 355 / approx. 30
